Yamaha EF7000 - Fuel Cock Strainer

2-11
CHK
ADJ
PERIODIC MAINTENANCE
FUEL COCK STRAINER
WARNING
Do not smoke, and keep away from open
flames, sparks, or any other source of fire
when handling or in the vicinity of fuel.
1. Turn the fuel cock lever to the “OFF” posi-
tion.
2. Remove:
9 Strainer cup 1
9 Gasket 2
9 Fuel cock strainer 3
3. Check:
9 Fuel cock strainer
Damage → Replace.
Dirt/clog → Clean.
TIP
Clean the fuel cock strainer with clean gaso-
line, and then dry it thoroughly.
4. Install:
9 Fuel cock strainer
9 Gasket
9 Strainer cup
1.3 Nm (0.13 m · kgf, 0.94 ft · lbf)
WARNING
Make sure that the strainer cup is tight-
ened securely.
1
2
3
