Yamaha EF7000 - MUFFLER

3-10
ENG
MUFFLER
1
2
3
4
5
6
7
8
2
12 Nm (1.2 m · kgf, 8.7 ft · lbf)
2.0 Nm (0.20 m · kgf, 1.4 ft · lbf)
16 Nm (1.6 m · kgf, 12 ft · lbf)
16 Nm (1.6 m · kgf, 12 ft · lbf)
Order Job/Parts to remove Q’ty Remarks
Removing the muffler Remove the parts in the order listed.
1 Muffler cover 1
2 Muffler damper 2
3 Muffler band 1
4 Muffler cap 1
5 Muffler screen 1
6 Washer 1
7 Muffler 1
8 Exhaust gasket 1
MUFFLER
