Yamaha EF7000 - BATTERY

5-18
ELEC
BATTERY (EF7000E/EF7200E/EF7200DE)
1
2
3
3
4
5
6
Order Job/Parts to remove Q’ty Remarks
Removing the battery Remove the parts in the order listed.
1 Negative battery lead 1 Disconnect.
2 Positive battery lead 1 Disconnect.
3 Wing nut 2
4 Battery mounting plate 1
5 Battery mounting rod 2
6 Battery 1
BATTERY (EF7000E/EF7200E/EF7200DE)
