3-2
ENG
CONTROL BOX
3.8 Nm (0.38 m á kgf, 2.8 ft á lbf)
7 Nm (0.7 m á kgf, 5.1 ft á lbf)
7 Nm (0.7 m á kgf, 5.1 ft á lbf)
10
11
12
13
14
7
8
9
Order Job/Parts to remove Q’ty Remarks
7 Economy control solenoid lead con-
nector
2
8 Oil level switch lead connector 1
9 TCI unit lead connector 2
10 Starter relay lead connector 1
11 Charging coil lead connector 2
12 Auto choke lead connector 2
13 Fuel cut solenoid valve lead connec-
tor
2
14 Positive battery lead connector 1
