3-8
ENG
FUEL TANK, CANISTER
7 Nm (0.7 m á kgf, 5.1 ft á lbf)
7 Nm (0.7 m á kgf, 5.1 ft á lbf)
0.8 Nm (0.08 m á kgf, 0.58 ft á lbf)
1.3 Nm (0.13 m á kgf, 0.94 ft á lbf)
16 Nm (1.6 m á kgf, 12 ft á lbf)
11
12
14
15
16
17
18
19
13
Order Job/Parts to remove Q’ty Remarks
11 Fuel tank cap 1
12 Fuel tank filter 1
13 Fuel level gauge 1
14 Fuel cock 1
15 Strainer cup 1
16 Gasket 1
17 Fuel cock strainer 1
18 Gasket 1
19 O-ring 1
