3-14
ENG
GENERATOR
42 Nm (4.2 m · kgf, 30 ft · lbf)
7 Nm (0.7 m · kgf, 5.1 ft · lbf)
5
6
10 Nm (1.0 m · kgf, 7.2 ft · lbf)
4.5 Nm (0.45 m · kgf, 3.3 ft · lbf)
9 Nm (0.9 m · kgf, 6.5 ft · lbf)
3.8 Nm (0.38 m · kgf, 2.8 ft · lbf)
3.8 Nm (0.38 m · kgf, 2.8 ft · lbf)
Order Job/Parts to remove Q’ty Remarks
5 Rotor assembly 1
6 Generator fan 1
A
For EF7200DE
B
Except for EF7200DE
