3-19
ENG
PISTON, CAMSHAFT, CRANKCASE, AND
CRANKSHAFT
10
10 Nm (1.0 m · kgf, 7.2 ft · lbf)
7 Nm (0.7 m · kgf, 5.1 ft · lbf)
27 Nm (2.7 m · kgf, 20 ft · lbf)
12 Nm (1.2 m · kgf, 8.7 ft · lbf)
30 Nm (3.0 m · kgf, 22 ft · lbf)
1st
2nd
27 Nm (2.7 m · kgf, 20 ft · lbf)
10 Nm (1.0 m · kgf, 7.2 ft · lbf)
9
8
7
Order Job/Parts to remove Q’ty Remarks
7 Flyweight shaft assembly 1
8 Clip 1
9 Governor shaft 1
10 Negative battery lead 1 EF7000E/EF7200E/EF7200DE
To Next Page
