Yamaha F90D - Propeller Shaft Housing

6D81G11
6-10
1
2
3
4
5
6
7
8
9
Propeller shaft housing
6
No. Part name Q’ty Remarks
1 Slider 1
2 Shift plunger 1
3 Dog clutch 1
4Spring 1
5 Propeller shaft 1
6 Shim 1 0.3 mm
7 Washer 1
8 Reverse gear 1
9 Thrust washer 1
10 Ball bearing 1
Not reusable
11 O-ring 1
Not reusable
12 Propeller shaft housing 1
13 Straight key 1
14 Needle bearing 1
15 Oil seal 2
Not reusable
16 Claw washer 1
17 Ring nut 1
Lower unit / Propeller shaft housing
