Yamaha F90D - Removing the Propeller Shaft Housing Assembly; Disassembling the Propeller Shaft Assembly; Disassembling the Propeller Shaft Housing

LOWR
Lower unit
6-11
6D81G11
Removing the propeller shaft
housing assembly
1. Straighten the claw washer tabs
a
, and
then remove the ring nut and claw
washer.
2. Pull out the propeller shaft housing
assembly.
3. Remove the propeller shaft assembly.
Disassembling the propeller shaft
assembly
1. Remove the spring
1
, and then remove
the cross pin
2
, dog clutch
3
, slider and
shift plunger.
Disassembling the propeller shaft
housing
1. Remove the reverse gear and thrust
washer.
2. Remove the ball bearing.
CAUTION:
Do not reuse the bearing, always replace
it with a new one.
Gland nut wrench
1
: YB-34447
Bearing housing puller
2
: YB-06207
Universal puller
3
: YB-06117
Slide hammer
1
: YB-06096
