BRKT
Bracket unit
7-25
6D81G11
Power trim and tilt motor
7
No. Part name Q’ty Remarks
1 Power trim and tilt motor 1
2Bolt 4 M6
×
20 mm
3O-ring 1
Not reusable
4 Joint 1
5O-ring 1
Not reusable
6 Reservoir cap 1
7Screw 3 ø5
×
25 mm
8Stator 1
9O-ring 1
Not reusable
10 Armature 1
11 Washer 1
12 Bushing 1
13 Wire lead 1
14 Screw 2 ø4
×
15 mm
15 Brush 1
16 Brush 1
17 Brush holder 1
1
2
3
4
5
6
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
7 N
·
m (0.7 kgf
·
m, 5.2 ft
·
Ib)
AA
AA
AA
9
10
11
12
8
7
14
13
14
15
17
18
16
19
19
20
21
23
22
AA
AA
S6D87290
