Yamaha F90D - Drive Shaft and Lower Case

LOWR
Lower unit
6-15
6D81G11
Drive shaft and lower case
6
No. Part name Q’ty Remarks
1 Drive shaft 1
2 Taper roller bearing 1
Not reusable
3 Pinion shim —
4Sleeve 1
5Hose 1
6 Plastic tie 1
Not reusable
7 Joint 1
8Nut 1
9 Cooling water inlet cover 2
10 Screw 1 ø5
×
40 mm
11 Seal 1
12 Plate 1
13 Forward gear shim —
14 Taper roller bearing 1
Not reusable
15 Needle bearing 1
Not reusable
16 Forward gear assembly 1
17 Needle bearing 1
