Yamaha F90D - Assembling the Drive Shaft; Installing the Drive Shaft; Installing the Propeller Shaft Housing

6D81G11
6-20
1
2
3
4
5
6
7
8
9
2. Install a new needle bearing into the for-
ward gear to the specified depth.
Assembling the drive shaft
1. Install a new drive shaft bearing into the
drive shaft using a press.
Installing the drive shaft
1. Install the forward gear, then the drive
shaft assembly, pinion, and pinion nut,
and then tighten the nut to the specified
torque.
Installing the propeller shaft housing
1. Install the washer
1
and propeller shaft
assembly
2
into the propeller shaft
housing assembly
3
.
2. Apply grease to a new O-ring.
Forward gear outer race installer
1
:
YB-06085
Bearing housing needle bearing
remover
1
:
YB-06112
Driver handle (large)
2
: YB-06071
Depth
a
:
1.20
±
0.25 mm (0.05
±
0.01 in)
General pipe
1
:
a
= 33 mm (1.30 in)
b
= 28 mm (1.10 in)
Drive shaft holder
1
: YB-06151
T
R
.
.
Pinion nut:
93 N·m (9.3 kgf·m, 68.6 ft·lb)
S68S6410
1
Drive shaft and lower case
