Page #15 background image
SPEC
Specifications
2-1
6D81G11
General specifications
2
Item Unit
Model
F90TR
Dimension
Overall length mm (in) 817 (32.2)
Overall width mm (in) 479 (18.9)
Overall height
(L) mm (in) 1,582 (62.3)
(X) mm (in) 1,710 (67.3)
Boat transom height
(L) mm (in) 508 (20.0)
(X) mm (in) 635 (25.0)
Weight
(without propeller)
(L) kg (lb) 168 (370)
(X) kg (lb) 172 (379)
Performance
Maximum output kW (hp) 66.2 (90) at 5,500 r/min
Full throttle operating range r/min 5,000–6,000
Maximum fuel consumption L (US gal,
Imp gal)/hr
33.0 (8.72, 7.26) at 6,000 r/min
Engine idle speed r/min 700
±
50
Power unit
Type In-line, 4-stroke, DOHC, 16 valves
Cylinder quantity 4
Total displacement cm
3
(cu. in) 1,596 (97.39)
Bore
×
stroke mm (in) 79.0
×
81.4 (3.11
×
3.20)
Compression ratio 9.6
Control system Remote control
Starting system Electric
Fuel system Fuel injection
Ignition control system TCI
Advance type Micro computer
Maximum generator output V, A 12, 25
Spark plug LFR5A-11 (NGK)
Cooling system Water
Exhaust system Propeller boss
Lubrication system Wet sump
