Yamaha F90D - Installing the Water Pump and Shift Rod

LOWR
Lower unit
6-21
6D81G11
3. Install the shim
4
and propeller shaft
housing assembly
5
into the lower case,
and then install the straight key
6
, claw
washer
7
, and ring nut
8
.
4. Tighten the ring nut to the specified
torque.
NOTE:
• To secure the ring nut, bend one tab
a
of
the claw washer into a slot in the ring nut.
• Bend all other tabs toward the propeller
shaft housing assembly.
Installing the water pump and shift
rod
1. Install the shift rod assembly
1
.
NOTE:
Install the shift rod assembly into the lower
case, turn it counterclockwise 90°
a
, and
then push it down
b
to connect it to the shift
slider
2
.
2. Install new oil seals into the oil seal hous-
ing as shown.
NOTE:
Install an oil seal halfway into the oil seal
housing, then the other oil seal.
Gland nut wrench
9
: YB-34447
T
R
.
.
Ring nut
8
:
103 N·m (10.3 kgf·m, 76.0 ft·lb)
Propeller shaft oil seal installer
3
:
YB-06269
Driver handle (large)
4
: YB-06071
Depth
c
:
4.0
±
0.5 mm (0.16
±
0.02 in)
S60C6430
A
LT
572
2
a
b
1
