15. Install the tilt cylinder end screw
8
, and
then tighten it to the specified torque.
CAUTION:
Do not damage the check valve
b
when
tightening the end screw.
16. Install the free piston
U
into the tilt cylin-
der
G
by installing the circlip
V
.
17. Install the cylinder base
W
, springs
X
,
and washer
Y
into the tilt cylinder with
the circlip
Z
.
Assembling the power trim and tilt
unit
1. Hold the trim cylinder in a vise using alu-
minum plates on both sides.
2. Install the filters and gear pump assem-
bly
1
by installing the bolts
2
, then tight-
ening them to the specified torques.
3. Install the manual valve
3
and reservoir
cap
4
.
4. Fill the reservoir with the recommended
fluid to the correct level as shown.
Trim cylinder wrench: YB-06175-2B
T
R
.
.
Tilt cylinder end screw
8
:
80 N·m (8.0 kgf·m, 59.0 ft·lb)
T
R
.
.
Gear pump bolt
2
:
5 N·m (0.5 kgf·m, 3.7 ft·lb)
Reservoir cap
4
:
7 N·m (0.7 kgf·m, 5.2 ft·lb)
3
4
2
2
1
S6D87440
