Yamaha F90D - Page 150

6D81G11
1
2
3
4
5
6
7
8
9
Tilt cylinder and trim cylinder.....................................................................7-35
Disassembling the trim cylinder...............................................................7-38
Disassembling the tilt cylinder .................................................................7-38
Checking the tilt cylinder and trim cylinder ..............................................7-39
Checking the valves ................................................................................7-39
Assembling the tilt cylinder ......................................................................7-39
Assembling the power trim and tilt unit....................................................7-41
Bleeding the power trim and tilt unit ........................................................7-43
Installing the power trim and tilt unit ........................................................7-44
Bleeding the power trim and tilt unit (built-in) ..........................................7-44
Power trim and tilt electrical system..........................................................7-45
Checking the fuse....................................................................................7-45
Checking the power trim and tilt relay .....................................................7-45
Checking the power trim and tilt switch ...................................................7-46
Checking the trim sensor.........................................................................7-46
