Yamaha F90D - Page 157

BRKT
Bracket unit
7-7
6D81G11
7
No. Part name Q’ty Remarks
1 Oil seal 1
Not reusable
2Screw 6 ø6
×
10 mm
3Gasket 1
Not reusable
4O-ring 1
Not reusable
5Shaft 1
6O-ring 1
Not reusable
7 Oil seal 1
Not reusable
8 Oil seal 2
Not reusable
9O-ring 1
Not reusable
10 Oil seal housing 1
11 Screw 4 ø6
×
10 mm
12 Oil pump assembly 1
S6D87040
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
12
WR-No.1
WR-No.1
1
2
3
5
6
4
E
T
R
.
.
4 N
•
m (0.4 kgf
•
m, 3.0 ft
•
Ib)
E
11
9
10
8
7
E
E
E
E
E
E
WR-No.1
