Yamaha F90D - Page 181

BRKT
Bracket unit
7-31
6D81G11
7
No. Part name Q’ty Remarks
18 Holder 1
19 Spring 1
20 Washer 1
21 Up-relief valve seat 1
22 Bolt 2 M5
×
25 mm
23 O-ring 1
Not reusable
24 Shuttle piston 1
25 Bolt 2 M5
×
45 mm
26 Bolt 2 M5
×
50 mm
27 Filter 1
28 Plate 1
29 O-ring 2
Not reusable
30 Filter 2
31 O-ring 1
Not reusable
32 Manual valve 1
33 Circlip 1
S6D87360
T
R
.
.
5 N
·
m (0.5 kgf
·
m, 3.7 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
5 N
·
m (0.5 kgf
·
m, 3.7 ft
·
Ib)
T
R
.
.
5 N
·
m (0.5 kgf
·
m, 3.7 ft
·
Ib)
27
28
29
30
26
31
32
33
7
24
23
25
2
3
5
6
7
8
9
4
2
16
15
14
13
12
11
10
21
20
19
18
17
16
15
22
1
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
