Yamaha F90D - Page 70

6D81G11
5-4
1
2
3
4
5
6
7
8
9
5
No. Part name Q’ty Remarks
1Damper 1
2Grommet 2
3Grommet 1
4 Flywheel magnet cover 1
5 Power unit 1
6 Oil dipstick 1
7Gasket 1
Not reusable
8 Dowel 2
9Bolt 5 M6
×
16 mm
10 Bolt 6 M10
×
130 mm
11 Screw 2 ø6
×
40 mm
12 Nut 2
13 Apron 1
14 Bolt 2 M8
×
35 mm
15 Holder 1
S6D85010
1
7
8
9
10
11
12
13
14
2
3
4
5
6
15
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
1 42 N
·
m (4.2 kgf
·
m, 31.0 ft
·
Ib)
2 42 N
·
m (4.2 kgf
·
m, 31.0 ft
·
Ib)
LT
572
LT
LT
572
LT
E
Power unit
