Yamaha F90D - Page 73

POWR
Power unit
5-7
6D81G11
5
No. Part name Q’ty Remarks
1Screw 5 ø6
×
30 mm
2 Cover 1
3 Spark plug wire 4
4 Holder 2
5 Holder 2
6Bolt 1 M6
×
12 mm
7 Holder 1
8 Clamp 1
9Hose 1
10 Plastic tie 1
Not reusable
11 Ignition coil 2
12 Bracket 2
13 Bolt 4 M6
×
25 mm
14 Holder 2
15 Starter motor 1
16 Bolt 3 M8
×
45 mm
17 Terminal 1
S6D85040
T
R
.
.
29 N
·
m (2.9 kgf
·
m, 21.4 ft
·
Ib)
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
T
R
.
.
9 N
·
m (0.9 kgf
·
m, 6.6 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
11
1
2
3
5
5
3
4
4
27
28
8
9
29
6
7
10
25
26
24
15
23
17
18
19
16
14
13
13
12
13
22
21
20
LT
572
LT
31
30
