6 - 8
COOL
THERMOSTAT
EAS00460
THERMOSTAT
Order Job/Part Q’ty Remarks
Removing the thermostat assembly
Remove the parts in the order listed.
Side cowlings/front cowling assembly Refer to “COWLINGS AND COVERS” in
chapter 3.
Coolant Drain.
Refer to “CHANGING THE COOLANT” in
chapter 3.
Air cut-off valve assembly/hoses Refer to “AIR INDUCTION SYSTEM” in
chapter 7.
1 Plunger control unit hose 1 1 Disconnect.
2 Thermostat assembly inlet pipe 1
3 Coolant temperature sensor 1
4 Thermostat assembly breather hose 1 Disconnect.
5 Radiator inlet hose 1 Disconnect.
6 Thermostat assembly 1
For installation, reverse the removal
procedure.
