Yamaha FT60D - Cylinder block service

POWR
Power unit
5-37
6C13G11
Cylinder block
5
No. Part name Q’ty Remarks
1Bolt 10 M8
×
82 mm
2Bolt 10 M6
×
35 mm
3 Crankcase 1
4 Main bearing 10
5Bolt 8 M6
×
30 mm
6 Connecting rod assembly 4
7 Connecting rod bearing 8
8 Crankshaft 1
9 Oil seal 1
Not reusable
10 Oil seal 1
Not reusable
11 Cylinder block 1
12 Bolt 1 M6
×
14 mm
13 Holder 1
14 Clip 8
15 Piston 4
16 Piston ring assembly 4
17 Piston pin 4
