Yamaha FT60D - Tightening torques

SPEC
Specifications
2-21
6C13G11
Tightening torques
2
Specified torques
Part to be tightened Thread size
Tightening torques
N·mkgf·mft·lb
Fuel system
Fuel filter cup — 30.32.2
Fuel pump screw M5 3 0.3 2.2
Fuel pump valve screw M3 0.5 0.05 0.36
Idle speed control screw M5 4 0.4 3.0
Sensor assembly screw M5 4 0.4 3.0
Fuel cooler screw M6 3 0.3 2.2
Fuel rail mounting bolt M6 9 0.9 6.6
Throttle body mounting bolt M6 9 0.9 6.6
Pressure regulator bolt M6 5 0.5 3.7
Drain screw — 1.5 0.15 1.1
Joint screw — 40.43.0
Vapor separator cover screw M5 3 0.3 2.2
Plate screw M4 2 0.2 1.5
Power unit
Power unit mounting bolt M8 27 2.7 20.0
Shift position switch screw M4 2 0.2 1.5
Stator coil bracket bolt M6 4 0.4 3.0
Pulser coil bolt M5 4 0.4 3.0
Flywheel magnet nut M20 157 15.7 115.8
Starter motor bolt M8 29 2.9 21.4
Starter motor terminal nut M8 9 0.9 6.6
Starter relay lead bolt M6 4 0.4 3.0
Starter motor lead screw M4 2 0.2 1.5
Starter relay holder screw M6 3 0.3 2.2
Main and fuel pump relay screw M6 3 0.3 2.2
ECM cover screw M6 3 0.3 2.2
Self diagnosis connector screw M6 3 0.3 2.2
Ignition coil bolt M6 7 0.7 5.2
Oil filter — 18 1.8 13.3
PTT relay nut M6 4 0.4 3.0
PTT motor lead bolt M6 4 0.4 3.0
Positive battery lead nut M8 9 0.9 6.6
Drive sprocket nut M41 140 14.0 103.3
Driven sprocket bolt M10 38 3.8 28.0
Rocker arm lock nut M10 14 1.4 10.3
Rocker arm shaft bolt M8 18 1.8 13.3
