Yamaha FT60D - Lower unit service (F50, F60)

LOWR
Lower unit
6-5
6C13G11
Lower unit (F50, F60)
6
No. Part name Q’ty Remarks
1 Lower unit 1
2 Check screw 1
3Gasket 2
Not reusable
4Drain screw 1
5 Bolt 4 M10
×
40 mm
6 Dowel 2
7Bolt 1 M8
×
35 mm
8 Anode 1
9Spacer 1
10 Propeller 1
11 Washer 1
12 Washer 1
13 Propeller nut 1
14 Cotter pin 1
Not reusable
15 Trim tab 1
16 Bolt 1 M8
×
25 mm
17 Bolt 1 M8
×
60 mm
