Yamaha FT60D - Assembling the Oil Pan

BRKT
Bracket unit
7-19
6C13G11
Assembling the oil pan
1. Install a new gasket
1
onto the exhaust
guide
2
.
2. Install the oil strainer
3
, a new gasket,
and the housing onto the exhaust guide,
and then tighten the bolts to the specified
torque.
NOTE:
Align the projection
a
of the oil strainer with
the rib of the housing.
3. Install the oil pan
4
, and then tighten the
bolts finger tight.
4. Install a new gasket, the exhaust mani-
fold
5
, and the bolts, and then tighten
the bolts finger tight.
5. Tighten the exhaust manifold bolts
6
,
then the oil pan bolts
7
, and then tighten
them to the specified torques.
6. Install the cooling water pipe
8
into the
plate
9
.
7. Install a new gasket, the plate
9
, a new
gasket, the muffler
0
, and the bolts into
the oil pan, and then tighten the bolts to
the specified torque.
S6C17140
2
1
S6C17150
3
a
S6C17160
T
R
.
.
Oil strainer bolt:
10 N·m (1.0 kgf·m, 7.4 ft·lb)
T
R
.
.
Exhaust manifold bolt
6
:
10 N·m (1.0 kgf·m, 7.4 ft·lb)
Oil pan bolt
7
:
27 N·m (2.7 kgf·m, 20.0 ft·lb)
SC617170
4
6
5
AA
LT
572
LT
LT
572
LT
7
