6C13G11
7-20
1
2
3
4
5
6
7
8
9
8. Install the muffler assembly
A
by insert-
ing the tip of the cooling water pipe
B
into the joint hole
b
of the upper case.
9. Install the muffler assembly bolts
C
, and
then tighten them.
10. Install the upper mount
D
and bolts into
the upper case, and then tighten the
bolts.
Assembling the upper case
1. Install the drive shaft bushing into the
upper case.
T
R
.
.
Muffler bolt:
10 N·m (1.0 kgf·m, 7.4 ft·lb)
LT
572
LT
0
S6C17180
8
9
AA
S6C17190
C
A
B
LT
572
LT
AA
AA
B
b
Driver rod LS
1: 90890-06605
Ball bearing attachment 2:
90890-06637
AA
LT
572
LT
S6C17200
D
S6C17240
2
1
Upper case
