POWR
Power unit
5-47
6C13G11
5. Install the piston with the “UP” mark on
the piston crown facing towards the fly-
wheel magnet.
NOTE:
Apply engine oil to the side of the pistons and
piston rings before installation.
6. Install half of the main bearings
9
into
the cylinder block
0
.
NOTE:
• Install the main bearings in their original
positions.
• Insert the projection
f
of each bearing into
the slots in the cylinder block.
7. Set the crankshaft
A
and oil seals
B
and
C
into the cylinder block as shown.
NOTE:
Apply engine oil to the inner oil seals before
installation.
8. Install the connecting rod caps
D
to the
connecting rods, and then tighten the
connecting rod bolts to the specified
torques in two stages.
Piston slider: 90890-06529
S6D55920
E
0
9
f
S6C15750
D
E
E
g
To Next Page
