Yamaha FT60D - Page 176

LOWR
Lower unit
6-33
6C13G11
Propeller shaft housing (FT50, FT60)
6
No. Part name Q’ty Remarks
1 Slider 1
2 Shift plunger 1
3Cross pin 1
4 Dog clutch 1
5Spring 1
6 Propeller shaft 1
7 Washer 1
8 Reverse gear 1
9 Thrust washer 1
10 Ball bearing 1
Not reusable
11 O-ring 1
Not reusable
12 Propeller shaft housing 1
13 Straight key 1
14 Needle bearing 1
15 Oil seal 2
Not reusable
16 Claw washer 1
17 Ring nut 1
