FUEL
Fuel system
4-5
6C13G11
4
No. Part name Q’ty Remarks
1Screw 4 ø5
×
43 mm
2 Cover 1
3Seal 1
Not reusable
4 Fuel pump body 2 assembly 1
5 Diaphragm 1
6Pin 1
7Spring 1
8 Fuel pump body 1 1
9Nut 4
10 Spring 1
11 Plunger 1
12 Spring washer 4
