Yamaha FT60D - Page 99

6C13G11
5-8
1
2
3
4
5
6
7
8
9
5
No. Part name Q’ty Remarks
1 Timing belt 1
2 Nut 1 Width across flats: 41 mm (1.6 in)
3 Retaining plate 1
4 Drive sprocket 1
5 Bolt 1 M10
×
35 mm
6 Washer 1
7 Driven sprocket 1
8 Dowel 1
9 Woodruff key 1
Power unit
