Yamaha QL5 Reference Manual

Setup
Reference Manual
187
CREATE USER KEY window
1 USER NAME
Displays the user name. Press this area to access a keyboard window, in which you can
enter a user name of up to eight characters.
2 COMMENT
Displays a comment about the user. Press this area to access a keyboard window, in
which you can enter a comment of up to 32 characters.
3 PASSWORD
Enables you to specify a password. Press this area to access a keyboard window, in which
you can enter a password of up to eight characters.
4 POWER USER
Specifies whether Power User privileges will be granted to this user.
5 ACCESS PERMISSION
These settings specify the range of operations that the user can perform. For details on
each item, refer to page 190.
NOTE
In the case of the QL1, faders that do not exist on the model will not be shown.
Logging-in
To operate the QL series console, you must log in as the Administrator, Guest, or a User.
User settings for the Administrator and Guest are saved in the console itself. However, to log
in as a User you must either select a key that is saved in the console itself, or connect the
USB flash drive in which a user authentication key has been saved. If you use a user
authentication key on a USB flash drive, you will continue as the logged-in user even if you
remove the USB flash drive after logging-in.
NOTE
If the power is turned off and then on again, the console will generally start up in the log-in state
in which the power was turned off. If a user password has been assigned, you will need to enter
the password. However if you cancel the input, you will be forcibly logged-in as Guest.
 Logging-in as Administrator
NOTE
• If no Administrator password has been set, you will simply be logged-in in step 3 when you press
the LOGIN button. If a password has been set, a keyboard window will appear, allowing you to
enter the password.
• If the password was incorrect, a message of “Wrong Password!” will appear near the bottom of
the screen.
1
2 3 4
5
STEP
1. In the Function Access Area, press the SETUP button.
2. In the SETUP screen, press the CURRENT USER button.
3. In the LOGIN window, press the ADMINISTRATOR button.
4. Enter the password and press the OK button.
SETUP screen LOGIN window

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
