Yamaha QL5 Reference Manual

Scene memory
Reference Manual
89
SCENE LIST window
1 FOCUS button
Enables or disables the Focus function for each scene.
2 SET popup button
Press this button to access the FOCUS RECALL popup window, which allows you to
select the parameters that will be subject to recall.
3 FOCUS PARAMETER indicators
These indicators show the focus recall settings that are specified for each scene.
4 CURRENT SETTING field
Specifies the content that will be saved by the next scene store operation.
FOCUS RECALL window
Sets the parameters that will be recalled.
1 CLEAR ALL button/SET ALL button
Turns off (or on) all focus channel selections and global focus parameter settings.
2 Focus channel display field
Indicates the target channel for a Recall operation. The view of this field is the same as
that in the RECALL SAFE window.
1 2
3
4
8
6
5
9
1
2
4
7
0
3
All parameters are affected by Recall on these channels.
Some parameters are affected by Recall on these channels.
Recall has been canceled on these channels.
