Yamaha QL5 Reference Manual

Setup
Reference Manual
191
• WITH SEND ........................ Restricts operation of that channel’s send parameters.
(From MIX, From MATRIX)
• DCA MASTER .................... Restricts operation of that channel’s DCA group fader,
ON/OFF, and ICON/COLOR/NAME.
• DCA GROUP ASSIGN........ Restricts changes of assignment to that DCA group.
• SET BY SEL ....................... If this button is on, you can press the panel [SEL] key of
a channel to enable or disable the above-mentioned
operating restrictions for that channel.
2 CURRENT SCENE
Specifies the operations that can be performed on the current scene memory.
• INPUT PATCH/INPUT NAME
..................... Restricts operations for input channel patching and
names.
• OUTPUT PATCH/INPUT NAME
..................... Restricts operations for output channel patching and
names.
• BUS SETUP........................ Restricts operations for bus setup.
• GEQ RACK/EFFECT RACK/PREMIUM RACK
..................... Restricts operations for the racks. Press this area to open
the RACK USER LEVEL window, in which you can set
this restriction.
However, there will be no restriction on operating the
MIDI CLK button displayed for delay-type and
modulation-type effects, or the PLAY/REC button
displayed for the FREEZE effect.
• MUTE GROUP ASSIGN/MUTE GROUP MASTER
..................... Restricts operations for mute group assignment and
mute group master.
NOTE
In the case of the QL1, faders that do not exist on the model will not be shown.
3 SCENE LIST
Specifies the operations that can be performed on scene memories.
• STORE/SORT operations
• RECALL operations
4 LIBRARY LIST
Specifies the operations that can be performed on libraries.
• STORE/CLEAR operations
• RECALL operations
5 FILE LOAD
Specifies the settings that will be applied when a file is loaded from a USB flash drive.
The user authentication key contains settings such as the user level, preferences, and the
USER DEFINED key settings (USER SETUP settings). Other data is saved in an “ALL” file.
The “ALL” file also includes the USER SETUP settings of the Administrator and the Guest.
• USER SETUP (Preference and USER DEFINED keys settings)
• SYSTEM SETUP/MONITOR SETUP
• CURRENT SCENE
• SCENE LIST
•LIBRARY LIST
6 MONITOR SETUP
Specifies the monitor setup operations that can be performed.
•OSCILLATOR
• TALKBACK
7 SYSTEM SETUP
Specifies the system setup operations that can be performed.
• MIXER SETUP
• OUTPUT PORT
• MIDI/GPI
• DANTE SETUP
NOTE
• The content that is restricted with the DANTE SETUP button is as shown below.
• Changing the CONSOLE ID
• Changing the SECONDARY PORT setting
• Changing control of DANTE PATCH changes (THIS CONSOLE or DANTE CONTROLLER)
• Changing BIT DEPTH
• Changing LATENCY
• Changing DEVICE MOUNT
• Changing REMOTE HA ASSIGN
• Changing the Dante Input Patch
• Changing the Dante Output Patch
• Changing the Dante Input Patch Library (Changing Store, Recall, Clear, Library Name)
• Changing the PREFERED MASTER
• If an operation is restricted, the message “This operation is not allowed.” is displayed at the
bottom of the screen.
• With the factory settings, this is turned off (no restrictions).
8 SET ALL/CLEAR ALL button
Permits/clears all items.

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
