*1) SELECTED CH, Automixer ch1-6
*2) SELECTED CH, QL5: CH1-CH64, QL1: CH1-CH32, ST IN 1-ST IN 8, MIX1-MIX16, MTRX1-MTRX8, STEREO,
MONO (C)
*3) SELECTED CH, QL5: CH1-CH64, QL1: CH1-CH32, ST IN 1L-ST IN 8R
*4) SELECTED CH, QL5: CH1-CH64, QL1: CH1-CH32, ST IN 1-ST IN 8
*5) SELECTED CH, QL5: CH1-CH64, QL1: CH1-CH32, ST IN 1L-ST IN 8R, MIX1-SIX16
*6) MIX1-MIX16, MTRX1-MTRX8, ST L, ST R, MONO
*7) SELECTED CH, QL5: CH1-CH64, QL1: CH1-CH32, ST IN 1L-ST IN 8R, MIX1-MIX16, ST L, ST R, MONO (C)
*10) #1-#4
*11) REMOTE HA #1-#8
*12) QL5: DANTE1-64, QL1: DANTE1-32, QL5: OMNI 1-OMNI 16, QL1: OMNI 1-OMNI 8, SLOT1 1-SLOT1 16,
SLOT2 1-SLOT2 16, DIGITAL OUT L, DIGITAL OUT R
*13) SELECTED CH, MIX1-MIX16, MTRX1-MTRX8, STEREO, MONO (C)
*14) SELECTED CH, QL5: CH1-CH64, QL1: CH1-CH32
*a) If not mounted in the RACK, “----” is displayed.
*b) If there are no parameters, “----” is displayed.
EQ
HIGH MID Q
*2)
HIGH MID FREQUENCY
HIGH MID GAIN
HIGH Q
HIGH FREQUENCY
HIGH GAIN
EXTERNAL HA GAIN1–GAIN8 *10)
HPF FREQUENCY *4)
I/O DEVICE GAIN1–GAIN32 *11)
INPUT DELAY DELAY TIME *3)
INPUT GAIN
ANALOG GAIN
*4)
DIGITAL GAIN
MIDI CONTROL CHANGE
CTRL 1–CTRL 31 —
CTRL 33–CTRL 95 —
CTRL 102–CTRL 119 —
MONITOR
DIMMER LEVEL —
TALKBACK DIMMER LEVEL —
MONITOR DELAY —
MONITOR FADER —
OSCILLATOR
LEVEL —
FREQUENCY —
LEVEL(EVEN) —
FREQUENCY(EVEN) —
HPF —
LPF —
WIDTH —
INTERVAL —
OUTPUT LEVEL LEVEL *6)
OUTPUT PORT
DELAY TIME
*12)
GAIN
PREMIUM RACK
Displays the PREMIUM RACK No. (1A-
8B) for the corresponding operation, as
well as the name of the mounted
PROCESSOR*a).
Displays the names of the 64
parameters for the PROCESSOR *b).
RECORDER
INPUT GAIN —
OUTPUT GAIN —
SCENE SELECT —
TO MIX LEVEL MIX1–MIX16 *3)
TO MATRIX LEVEL MATRIX1–MATRIX8 *7)
TO MIX PAN MIX1/2–MIX15/16 *3)
TO MATRIX PAN MATRIX1/2–MATRIX7/8 *7)
TO ST/MONO
PAN/BAL
*5)
CSR
Function PARAMETER 1 PARAMETER 2
To Next Page
