Setup
Reference Manual
206
C WITH DANTE SETUP AND I/O DEVICE button
If this is off, the DANTE SETUP and I/O device settings as well as word clock settings will
be omitted when a settings file is loaded.
NOTE
The DANTE SETUP settings SECONDARY PORT and CONSOLE ID will not be changed even
if the WITH DANTE SETUP AND I/O DEVICE button is on.
Saving the QL console’s internal data on a USB flash drive
All of the QL series console’s internal data can be saved on a USB flash drive as a setting file.
The saved file will have an extension of “.CLF.”
SAVE SELECT screen
1 TYPE field
Specifies the types of data to be saved. The view of the TYPE field will vary depending
on the tab you select.
•ALL tab
This button selects all the items.
•SCENE tab
This button selects scene memories.
• INPUT/OUTPUT tab
The following table lists the items that you can select.
• EFFECT/GEQ tab
The following table lists the items that you can select.
• PREMIUM tab
The following table lists the items that you can select.
STEP
1. In the SAVE/LOAD window, press the SAVE button.
2. In the SAVE SELECT screen, select the data to be saved, the data type, and the save
destination.
3. In the SAVE SELECT screen, press the SAVE button.
4. Enter a file name and comment.
5. Press the SAVE button to execute the Save operation.
Button Data content
IN CH LIB Input channel library
OUT CH LIB Output channel library
IN EQ LIB Input EQ library
OUT EQ LIB Output EQ library
DYNA LIB Dynamics library
Button Data content
EFFECT LIB Effect library
GEQ LIB GEQ library
8 PEQ LIB 8Band PEQ library
Button Data content
5033 LIB Portico 5033 library
5043 LIB Portico 5043 library
U76 LIB U76 library
Opt-2A LIB Opt-2A library
EQ-1A LIB EQ-1A library
DynaEQ LIB DynamicEQ library
BussComp LIB Buss Comp 369 library
To Next Page
