Yamaha QL5 Reference Manual

Data List
30
Mixing parameter operation applicability
This table indicates which settings affect the behavior of each input channel and output channel parameter.
It also indicates whether or not they can be linked as stereo, and whether or not they are relevant to the RECALL SAFE, GLOBAL PASTE, and USER LEVEL settings, and a channel library.
 Input channels
Parameter
Stereo
*1
CHANNEL LINK
RECALL SAFE, FOCUS RECALL, GLOBAL PASTE
*8
USER LEVEL
Channel
Library
ALL Parameter Select button
HA
Gain
O
*10
HA
*10
O HA, GLOBAL HA HA O
Gain Compensation O HA O HA, GLOBAL HA HA O
+48V
O HA, GLOBAL HA HA O
Phase
O HA, GLOBAL HA HA O
AG-DG Link O HA O HA, GLOBAL HA HA O
Digital Gain
O
*10
DIGITAL GAIN
*10
O DIGITAL GAIN HA O
Name, Icon, Color
O INPUT NAME, GLOBAL INPUT NAME INPUT NAME O
Input Patch
O INPUT PATCH, GLOBAL INPUT PATCH INPUT PATCH
LR-MONO
SELECT
* ST IN channels only O
O *14 INPUT PROCESSING O
Insert1,
Insert2
Out Patch
O INPUT INSERT PATCH, GLOBAL INPUT PATCH INPUT PATCH
In Patch O INPUT INSERT PATCH, GLOBAL INPUT PATCH INPUT PATCH
+48V, Gain, Gain Compensation INPUT INSERT PATCH, GLOBAL HA HA
On INPUT INSERT O INPUT INSERT INPUT PROCESSING O
Point
INPUT INSERT O INPUT INSERT INPUT PROCESSING O
Direct Out
Out Patch
O INPUT DIRECT OUT, GLOBAL INPUT PATCH INPUT PATCH
On, Level DIRECT OUT O INPUT DIRECT OUT INPUT PROCESSING O
Point
DIRECT OUT O INPUT DIRECT OUT INPUT PROCESSING O
HPF O INPUT HPF O INPUT HPF INPUT PROCESSING O
Att O INPUT EQ O INPUT EQ INPUT PROCESSING O
EQ O INPUT EQ O INPUT EQ INPUT PROCESSING O
Dynamics1
Key-In Source
O INPUT DYNA1 INPUT PROCESSING
Key-In Filter O INPUT DYNAMICS1 O INPUT DYNA1 INPUT PROCESSING O
Others O INPUT DYNAMICS1 O INPUT DYNA1 INPUT PROCESSING O
Dynamics2
Key-In Source
O INPUT DYNA2 INPUT PROCESSING
Others O INPUT DYNAMICS2 O INPUT DYNA2 INPUT PROCESSING O
To Mix
On O
INPUT MIX ON
*2
O
INPUT MIX ON
*7
INPUT FADER/ON
*4
O
Level O
INPUT MIX SEND
*2
O
INPUT MIX SEND
*7
INPUT FADER/ON
*4
O
Pan/Balance
O
*11
O
INPUT MIX SEND
*7
INPUT FADER/ON
*4
O
Pre/Post O
INPUT MIX SEND
*2
O
INPUT MIX SEND
*7
INPUT PROCESSING
*4
O
Surround
Pan
O INPUT MIX SEND INPUT PROCESSING O
Divergence O
O INPUT MIX SEND INPUT PROCESSING O
LFE O
O INPUT MIX SEND INPUT PROCESSING O

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
