Operation
4
11. “MANUAL” mode
11.2.8.3 Jump to a point comment
[Procedure]
1) Press the
F 3
(JUMP) key in “MANUAL>POINT>COMMENT” mode.
The message “Enter point no. >” appears on the guideline.
Fig. 4-11-29
MANUAL>POINT>COMMENT 50%[MG][S0H0X]
————————————x———————y———————z———————r———
P7 = 100.00 250.00 15.00 30.00
P8 =
P9 = 122.62 -24.54 12.35 -23.11
Enter point no.>107_
COMNT: [ ]
[POS] 50.00 100.00 5.00 10.00
2) Enter the point comment to jump to, and press the key.
A jump is made to the designated point and its comment is then displayed.
Fig. 4-11-30
MANUAL>POINT>COMMENT 50%[MG][S0H0X]
————————————x———————y———————z———————r———
P107 = 340.05 250.03 115.00 34.54
340.05 200.05 115.00 34.54
P108 =
P109 = 122.62 -24.54 12.35 -23.11
EDIT TEACH JUMP VEL+ VEL-
COMNT:WAIT_POS 08 [ ]
[POS] 50.00 100.00 5.00 10.00
n
NOTE
Valid point numbers are from 0 to
9999.
