Yamaha RCX142 User Manual

4-185
4
Operation
12. “SYSTEM” mode
c
CAUTION
When making the Ethernet settings to
use TELNET, you will need to set any
other parameters than those shown
on the right. For more details, see the
Ethernet manual.
12.1.4.3 Setting the network parameters
When using Ethernet, you set four parameters including the parameter to enable or disable
the Ethernet board.
1.
2.
3.
4.
Parameter
Board condition
IP address
Subnet mask
Gateway
Meaning
Enables or disables the Ethernet board. When set to "VALID"
the Ethernet can be used. When set to "INVALID" Ethernet
cannot be used.
Sets the IP address.
Sets the subnet mask.
Sets the gateway.
[Procedure]
Fig. 4-12-52
SYSTEM>PARAM>OP.BRD V8.35
1.E_Net
VALID
2.
3.
4.
SELECT
1) In “SYSTEM>PARAM>OP. BRD” mode, select "E_Net" with the cursor keys and
press the
F 1
(SELECT) key.
Fig. 4-12-53
SYSTEM>PARAM>OP.BRD>SELECT V8.35
1.board condition
VALID
2.IP address
3.Subnet mask
4.gateway
5.port No
192.168. 0. 2
255.255.255. 0
192.168. 0. 1
23
EDIT JUMP
2) Select the parameter with the cursor (↑/↓) keys.
Fig. 4-12-54
SYSTEM>PARAM>OP.BRD>SELECT V8.35
1.board condition
VALID
2.IP address
3.Subnet mask
4.gateway
5.port No
192.168. 0. 2
255.255.255. 0
192.168. 0. 1
23
EDIT JUMP
