7 Wiring
7.2.1 Main Circuit
7-20
(1) Wire Sizes and Tightening Torques
 Power Regeneration Converter
Input Voltage
Model:
CACP-JU
Ter mi na l
Symbols
Ter mi na l Sc re w
Tightening
Tor qu e [N xm]
Wire Sizes
Three-phase,
200 VAC
15A3
L1, L2, L3 M6 2.5 to 3.0 AWG6
B1, B2 M5 2.0 to 2.4 AWG14
M5 2.0 to 2.4 AWG6
19A3
L1, L2, L3 M6 2.5 to 3.0 AWG4
B1, B2 M5 2.0 to 2.4 AWG14
M5 2.0 to 2.4 AWG4
22A3
L1, L2, L3 M6 2.5 to 3.0 AWG3
B1, B2 M5 2.0 to 2.4 AWG14
M5 2.0 to 2.4 AWG4
30A3
L1, L2, L3 M6 2.5 to 3.0 AWG2
B1, B2 M5 2.0 to 2.4 AWG14
M6 2.5 to 3.0 AWG4
45A3B
L1, L2, L3 M10 30 AWG3/0
B1, B2 M5 2.0 to 2.4 AWG14
M6 2.5 to 3.0 AWG1/0
Three-phase,
400 VAC
15D3
L1, L2, L3 M6 2.5 to 3.0 AWG8
B1, B2 M5 2.0 to 2.4 AWG14
M5 2.0 to 2.4 AWG7
19D3
L1, L2, L3 M6 2.5 to 3.0 AWG8
B1, B2 M5 2.0 to 2.4 AWG14
M5 2.0 to 2.4 AWG7
22D3
L1, L2, L3 M6 2.5 to 3.0 AWG7
B1, B2 M5 2.0 to 2.4 AWG14
M5 2.0 to 2.4 AWG7
