YASKAWA CACR-JU series User Manual

7.2 Σ-V-SD Driver
7-21
Wiring
7
 SERVOPACK for One Axis
∗1. For motor model: UAKJ-11CZ (Input voltage: Three-phase 200 VAC)
∗2. For motor model: UAKJ-11CZ (Input voltage: Three-phase 400 VAC)
Input Voltage
Model:
CACR-JU
Ter mi na l
Symbols
Ter mi na l Sc re w
Tightening
Tor qu e [N xm]
Wire Sizes
For Spindle
Motor
For
Servomotor
Three-phase,
200 VAC
028ACA
U, V, W (connector) – AWG8 AWG10
motor
(connector) – AWG8 AWG10
M4 1.2 to 1.4 AWG8 AWG10
036ACA
U, V, W (connector) – AWG8 AWG8
motor
(connector) – AWG8 AWG8
M4 1.2 to 1.4 AWG8 AWG8
065ACA
U, V, W M6 2.5 to 3.0
AWG4
(AWG6)
*1
AWG6
motor
M6 2.5 to 3.0
AWG4
(AWG6)
*1
AWG6
M4 1.2 to 1.4
AWG4
(AWG6)
*1
AWG6
084ACA
U, V, W M6 2.5 to 3.0 AWG2 AWG4
motor
M6 2.5 to 3.0 AWG2 AWG4
M5 2.0 to 2.4 AWG4 AWG4
102ACA
U, V, W M6 2.5 to 3.0 AWG1 AWG4
motor
M6 2.5 to 3.0 AWG1 AWG4
M5 2.0 to 2.4 AWG4 AWG4
125ACA
U, V, W M8 2.5 to 3.0 AWG2/0 –
motor
M8 2.5 to 3.0 AWG2/0 –
M6 2.5 to 3.0 AWG2 –
196ACA
U, V, W M10 30 AWG4/0 –
motor
M10 30 AWG4/0 –
M6 2.5 to 3.0 AWG1/0 –
Three-phase,
400 VAC
014DCA
U, V, W (connector) – AWG12 AWG14
motor
(connector) – AWG12 AWG14
M4 1.2 to 1.4 AWG12 AWG14
018DCA
U, V, W (connector) – AWG10 AWG10
motor
(connector) – AWG10 AWG10
M4 1.2 to 1.4 AWG10 AWG10
033DCA
U, V, W M6 2.5 to 3.0
AWG8
(AWG10)
*2
AWG10
motor
M6 2.5 to 3.0
AWG8
(AWG10)
*2
AWG10
M4 1.2 to 1.4
AWG8
(AWG10)
*2
AWG10
042DCA
U, V, W M6 2.5 to 3.0 AWG6 AWG8
motor
M6 2.5 to 3.0 AWG6 AWG8
M5 2.0 to 2.4 AWG6 AWG8
051DCA
U, V, W M6 2.5 to 3.0 AWG6 AWG8
motor
M6 2.5 to 3.0 AWG6 AWG8
M5 2.0 to 2.4 AWG6 AWG8
