YASKAWA CACR-JU series User Manual

4 Specifications and External Dimensions for Σ-V-SD Drivers
4.2.1 Specifications
4-12
(4) I/O Current
 SERVOPACK for One Axis
 SERVOPACK for Two Axes
Voltage
Capacity
(50%ED)
kW
Capacity
(Continu-
ous
Ratings)
kW
Model
Input
Current
(50%ED)
Arms
Input
Current
(Continu-
ous
Ratings)
Arms
Output
Current
(50%ED)
Arms
Output
Current
(Continu-
ous
Ratings)
Arms
270 VDC
5.5 3.7 CACR-JU028ACA 26 17 34 28
7.5 5.5 CACR-JU036ACA 35 26 46 36
15 11 CACR-JU065ACA 69 51 82 65
18.5 15 CACR-JU084ACA 85 69 100 84
22 18.5 CACR-JU102ACA 102 85 116 102
30 22 CACR-JU125ACA 138 102 160 125
45 37 CACR-JU196ACA 207 170 240 196
540 VDC
5.5 3.7 CACR-JU014DCA 13 9 17 14
7.5 5.5 CACR-JU018DCA 18 13 23 18
15 11 CACR-JU033DCA 36 27 41 32.5
18.5 15 CACR-JU042DCA 45 36 50 42
22 18.5 CACR-JU051DCA 53 45 58 51
Voltage
Max. Allowable
Motor Capacity
Model
Input Current
(Continuous
Ratings)
Output Current
(Continuous
Ratings/Axis)
270 VDC
1.5 CACR-JUM23ACA 14 11.6
2.0 CACR-JUM24ACA 19 18.5
3.0 CACR-JUM25ACA 28 24.8
540 VDC
1.5 CACR-JUM23DCA 7.3 5.4
2.0 CACR-JUM24DCA 9.7 8.4
3.0 CACR-JUM25DCA 15 11.9
