Three-Phase 200 V / 400 V Class
L3L3 L2L2 L1L1
L3 L2 L1
E
L3
L2
L1
PE
A
B
C
D
E
D
F
A
G
D
J
I
H
H
A – Ground the cable shield
B – Enclosure panel
C – Metal plate
D – Grounding surface (remove any paint
or sealant)
E – Drive
F – Motor cable (braided shield cable,
max. 20 m)
G – Motor
H – Cable clamp
I – Max. distance between drive and noise
filter
J – EMC noise filter
Figure C.4 EMC Filter and Drive Installation for CE Compliance
(Three-Phase 200 V / 400 V Class)
C.2 European Standards
232
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
