YASKAWA CIPR-GA50C series Technical Manual

Electrical Installation
3
3.15 Protect the Drive during Failures
YASKAWA SIEPC71061753C GA500 Technical Manual 113
Drive Model
Maximum Applicable Motor Output
kW (HP)
Time Delay Fuse
Semiconductor Protection Fuse Rated Current
Manufacturer: EATON/Bussmann
ND HD
Class J, CC, and T Fuse
Rated Current
A
Model
Fuse Rated Current
A
2042 11 (15) 7.5 (10) 70 FWH-150B 150
2056 15 (20) 11 (15) 90 FWH-200B 200
2070 18.5 (25) 15 (20) 110 FWH-200B 200
2082 22 (30) 18.5 (25) 125 FWH-225A 225
■ Three-Phase 400 V Class
Table 3.18 Factory-Recommended Branch Circuit Protection: Three-Phase 400 V Class
Drive Model
Maximum Applicable Motor Output
kW (HP)
Time Delay Fuse
Semiconductor Protection Fuse Rated Current
Manufacturer: EATON/Bussmann
ND HD
Class J, CC, and T Fuse
Rated Current
A
Model
Fuse Rated Current
A
4001 0.37 (1/2) 0.37 (1/2) 3 FWH-40B 40
4002 0.75 (1) 0.55 (3/4) 3.5 FWH-40B 40
4004 1.5 (2) 1.1 (2) 7 FWH-50B 50
4005 2.2 (3) 1.5 (3) 9 FWH-70B 70
4007 3.0 (4) 2.2 (3) 12 FWH-70B 70
4009 4.0 (5) 3.0 (4) 15 FWH-90B 90
4012 5.5 (7.5) 4.0 (5) 20 FWH-90B 90
4018 7.5 (10) 5.5 (10) 30 FWH-80B 80
4023 11.0 (15) 7.5 (10) 40 FWH-100B 100
4031 15.0 (20) 11.0 (15) 50 FWH-125B 125
4038 18.5 (25) 15.0 (20) 60 FWH-175B 175
4044 22.0 (30) 18.5 (25) 70 FWH-200B 200
4060 30.0 (40) 22.0 (30) 100 FWH-200B 200
