11.17 U: Monitors
YASKAWA SIEPC71061753C GA500 Technical Manual 457
No.
(Hex.)
Name Description MFAO Signal Level
U6-92
(07F2)
Online Speed
Shows the currently available communications speed.
10: 10 Mbps
100: 100 Mbps
No signal output available
U6-93
(07F3)
Online Duplex
Shows the currently available Duplex setting.
No signal output available
U6-98
(07F8)
First Fault
Shows the contents of the most recent communication options fault (DeviceNet, Modbus TCP/IP,
EtherNet/IP).
No signal output available
U6-99
(07F9)
Current Fault
Shows the contents of current fault from communication options (DeviceNet, Modbus TCP/IP,
EtherNet/IP).
No signal output available
◆ U8: DriveWorksEZ Monitors
No.
(Hex.)
Name Description MFAO Signal Level
U8-01
(1950)
DWEZ Monitor 1
Shows DWEZ Monitor 1. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-02
(1951)
DWEZ Monitor 2
Shows DWEZ Monitor 2. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-03
(1952)
DWEZ Monitor 3
Shows DWEZ Monitor 3. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-04
(1953)
DWEZ Monitor 4
Shows DWEZ Monitor 4. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-05
(1954)
DWEZ Monitor 5
Shows DWEZ Monitor 5. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-06
(1955)
DWEZ Monitor 6
Shows DWEZ Monitor 6. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-07
(1956)
DWEZ Monitor 7
Shows DWEZ Monitor 7. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-08
(1957)
DWEZ Monitor 8
Shows DWEZ Monitor 8. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-09
(1958)
DWEZ Monitor 9
Shows DWEZ Monitor 9. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-10
(1959)
DWEZ Monitor 10
Shows DWEZ Monitor 10.
No signal output available
U8-11
(195A)
DWEZ Version 1
Shows the Upper three digits of the user ID. When you click the setting button on the title bar of
the PC tool to open the setting screen, you can confirm the user ID with the primary user ID
display.
No signal output available
U8-12
(195B)
DWEZ Version 2
Shows the lower five digits of the user ID. When you click the setting button on the title bar of the
PC tool to open the setting screen, you can confirm the user ID with the primary user ID display.
No signal output available
U8-13
(195C)
DWEZ Version 3
Shows the software ID.
No signal output available
U8-18
(1961)
DWEZ Platform Ver
Shows the DriveWorksEZ platform version.
No signal output available
U8-21
(1964)
DWEZ Monitor 21
Shows DWEZ Monitor 21. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
