YASKAWA CIPR-GA50C series Technical Manual

2.5 Drive Models and Drive Watt Loss
36 YASKAWA SIEPC71061753C GA500 Technical Manual
2.5 Drive Models and Drive Watt Loss
Specification Model Ref.
No internal EMC filter
BxxxA
36
2xxxA
37
4xxxA
38
Built-in EMC Filter
BxxxE
39
2xxxE
40
4xxxE
41
◆ Drive Watt Loss (without Built-in EMC Filter)
■ Single-Phase 200 V Class
Table 2.2 Drive Watt Loss (HD, Fc = 2 kHz)
Model
The rated output
current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 0.8 2 7 4 11
B002 1.6 2 10 7 17
B004 3 2 13 13 26
B006 5 2 17 23 40
B010 8 2 30 37 67
B012 11 2 40 48 88
B018
*1
17.6 2 49 72 121
*1 There is not a finless-type B018 model.
Table 2.3 Drive Watt Loss (HD, Fc = Default Setting)
Model
The rated output
current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 0.8 10 8 5 13
B002 1.6 10 10 9 19
B004 3 10 14 16 30
B006 5 10 18 28 46
B010 8 8 31 42 73
B012 11 8 41 55 96
B018
*1
17.6 8 53 98 151
*1 There is not a finless-type B018 model.
Table 2.4 Drive Watt Loss (ND)
Model
The rated output
current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 1.2 2 8 6 14
B002 1.9 2 14 11 25
B004 3.5 2 14 17 31
B006 6.0 2 17 26 43
B010 9.6 2 36 50 86
B012 12.2 2 48 60 108
B018
*1
- 2 49 92 141
*1 There is not a finless-type B018 model.
