10.3 Model-Specific Specifications (Single-Phase 200 V Class)
330 YASKAWA SIEPC71061753C GA500 Technical Manual
10.3 Model-Specific Specifications (Single-Phase 200 V
Class)
Table 10.2 Ratings (Single-Phase 200 V Class)
Model B001 B002 B004 B006 B010 B012 B018
Maximum Applicable Motor
Output (kW)
HD
*1
0.1 0.25 0.55 1.1 1.5 2.2 4.0
ND
*2
0.2
0.18
0.37 0.75 1.1 2.2 3.0 -
Maximum Applicable Motor
Output (HP)
HD
*1
1/6 1/4 1/2 1 2 3 5
ND
*2
1/6 1/4 3/4 1.5 3 3 -
Input
Rated Input
Current (A)
HD (AC) 1.4 2.8 5.5 11 14.1 20.6
35.0
HD (DC) 1.4 2.8 5.5 11 14.1 20.6 35.0
ND (AC) 2.0 5.0 7.3 13.8 20.2 24.0
-
ND (DC) 2.0 5.0 7.3 13.8 20.2 24.0
-
Output
Rated Output
Capacity (kVA)
*3
HD 0.3 0.6 1.1 1.9 3 4.2 6.7
ND 0.5 0.7 1.3 2.3 3.7 4.6 -
Rated Output
Current (A)
HD 0.8 1.6 3 5 8 11
17.6
ND 1.2 1.9 3.5 6 9.6 12.2
-
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is one time each 10 minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is one time each 10 minutes.
Note:
Derating can be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 10 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz
maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• V/f, OLV, OLV/PM: 590 Hz
• AOLV/PM: 270 Hz
• EZOLV: 120 Hz
Measures for
Harmonics
AC reactor External options
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3
Factory option
Models BxxxE: Category C1 (Conducted emission)
External
options
Power Supply
Rated Voltage/Rated Frequency
• Single-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
HD 0.4 0.7 1.5 2.9 3.7 5.4
9.2
ND 0.5 1.3 1.9 3.6 5.3 6.3
-
*1 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 220 V.
