11.17 U: Monitors
458 YASKAWA SIEPC71061753C GA500 Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level
U8-22
(1965)
DWEZ Monitor 22
Shows DWEZ Monitor 22.
Unit: The number of decimal points shown is set with Q2-21.
10 V = 100%
U8-23
(1966)
DWEZ Monitor 23
Shows DWEZ Monitor 23.
Unit: The number of decimal points shown is set with Q2-22.
10 V = 100%
U8-24
(1967)
DWEZ Monitor 24
Shows DWEZ Monitor 24.
Unit: The number of decimal points shown is set with Q2-23.
10 V = 100%
U8-25
(1968)
DWEZ Monitor 25
Shows DWEZ Monitor 25.
Unit: The number of decimal points shown is set with Q2-24.
10 V = 100%
U8-31
(196E)
DWEZ Monitor 31
Shows DWEZ Monitor 31. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-32
(196F)
DWEZ Monitor 32
Shows DWEZ Monitor 32. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-33
(1970)
DWEZ Monitor 33
Shows DWEZ Monitor 33. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-34
(1971)
DWEZ Monitor 34
Shows DWEZ Monitor 34. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-35
(1972)
DWEZ Monitor 35
Shows DWEZ Monitor 35. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-36
(1973)
DWEZ Monitor 36
Shows DWEZ Monitor 36. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-37
(1974)
DWEZ Monitor 37
Shows DWEZ Monitor 37. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-38
(1975)
DWEZ Monitor 38
Shows DWEZ Monitor 38. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-39
(1976)
DWEZ Monitor 39
Shows DWEZ Monitor 39. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-40
(1977)
DWEZ Monitor 40
Shows DWEZ Monitor 40.
No signal output available
U8-51
(1982)
DWEZ Monitor 51
Shows DWEZ Monitor 51. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-52
(1983)
DWEZ Monitor 52
Shows DWEZ Monitor 52.
Unit: The number of decimal points shown is set with Q2-41.
10 V = 100%
U8-53
(1984)
DWEZ Monitor 53
Shows DWEZ Monitor 53.
Unit: The number of decimal points shown is set with Q2-42.
10 V = 100%
U8-54
(1985)
DWEZ Monitor 54
Shows DWEZ Monitor 54.
Unit: The number of decimal points shown is set with Q2-43.
10 V = 100%
U8-55
(1986)
DWEZ Monitor 55
Shows DWEZ Monitor 55.
Unit: The number of decimal points shown is set with Q2-44.
10 V = 100%
