7.7 Auto-Tuning Errors
294 YASKAWA SIEPC71061753C GA500 Technical Manual
Code Name Causes Possible Solutions
Er-12 Current Detection Error
There is a phase loss in the drive input power. (U/
T1, V/T2, W/T3)
Examine and repair motor wiring.
The current exceeded the current rating of the drive.
The output current is too low.
• Check the motor wiring for any short circuits between the
wires.
• Check and turn ON any magnetic contactors used between
motors.
• Replace the control board or the drive. For information about
replacing the control board, contact Yaskawa or your nearest
sales representative.
You tried Auto-Tuning without a motor connected
to the drive.
Connect the motor and do Auto-Tuning.
There was a current detection signal error. Replace the control board or the drive. For information about
replacing the control board, contact Yaskawa or your nearest sales
representative.
Code Name Causes Possible Solutions
Er-13 Leakage Inductance Alarm
The motor rated current value is incorrect. Correctly set the rated current indicated on the motor nameplate
and perform Auto-Tuning again.
The drive could not complete tuning for leakage
inductance in fewer than 300 seconds.
Examine and repair motor wiring.
Code Name Causes Possible Solutions
Er-14 Motor Speed Error 2
The motor speed was more than two times the
amplitude of speed reference during Inertia Tuning.
Decrease the value set in C5-01 [ASR Proportional Gain 1].
Code Name Causes Possible Solutions
Er-15 Torque Saturation Error
During Inertia Tuning, the output torque was more
than the value set in L7-01 to L7-04 [Torque Limit].
• Increase the value set in L7-01 to L7-04 [Torque Limit] as
much as possible.
• Decrease the values set for the frequency and amplitude of the
test signals used when doing inertia tuning. First, decrease the
test signal amplitude, and then do Inertia Tuning. If the error
continues, decrease the test signal frequency and do Inertia
Tuning again.
Code Name Causes Possible Solutions
Er-16 Inertia ID Error
The inertia found by the drive was too small or too
large during Inertia Tuning (10% or less, or
50000% or more).
• Decrease the values set for the frequency and amplitude of the
test signals used when doing inertia tuning. First, decrease the
test signal amplitude, and then do Inertia Tuning. If the error
continues, decrease the test signal frequency and do Inertia
Tuning again
• Correctly set the motor inertia as specified by the motor, and
do Inertia Tuning again.
Code Name Causes Possible Solutions
Er-17 Reverse Prohibited Error
b1-04 = 1 [Reverse Operation Selection = Reverse
Disabled]
Note:
You cannot do Inertia Tuning if the drive cannot
rotate the motor in reverse.
1. Enable reverse in the target machine.
2. Set b1-04 = 0 [Reverse Enabled].
3. Do Inertia Tuning again.
Code Name Causes Possible Solutions
Er-18 Back EMF Error
The result of the induced voltage tuning was not in
the applicable range.
1. Make sure that the input motor nameplate data is correct.
2. Do Auto-Tuning again and correctly set the motor nameplate
data.
Code Name Causes Possible Solutions
Er-19 PM Inductance Error
The Auto-Tuning results of the PM motor
inductance were not in the applicable range.
1. Make sure that the input motor nameplate data is correct.
2. Do Auto-Tuning again and correctly set the motor nameplate
data.
Code Name Causes Possible Solutions
Er-20 Stator Resistance Error
The Auto-Tuning results of the PM Motor Stator
Resistance were not in the applicable range.
1. Make sure that the input motor nameplate data is correct.
2. Do Auto-Tuning again and correctly set the motor nameplate
data.
Code Name Causes Possible Solutions
Er-25 HighFreq Inject Param Tuning Err
The motor data is incorrect. Do Stationary Auto-Tuning again.
Note:
If the drive detects Er-25 after doing Stationary Auto-Tuning,
the motor may not be able to use high frequency injection
control. Contact Yaskawa or your nearest sales representative
for more information.
