10.8 Drive Exterior and Mounting Dimensions
YASKAWA SIEPC71061753C GA500 Technical Manual 347
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4005A
108
(4.25)
128
(5.04)
154
(6.06)
96
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.5
(3.3)
4007A
108
(4.25)
128
(5.04)
154
(6.06)
96
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.5
(3.3)
4009A
108
(4.25)
128
(5.04)
154
(6.06)
96
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.5
(3.3)
4012A
140
(5.51)
128
(5.04)
143
(5.63)
128
(5.04)
6
(0.24)
118
(4.65)
5
(0.20)
65
(2.56)
5
(0.20)
M5
2.0
(4.4)
Table 10.31 Three-Phase 400 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4001E
108
(4.25)
128
(5.04)
126
(4.96)
96.0
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
8.5
(0.33)
5
(0.20)
M5
1.4
(3.1)
4002E
108
(4.25)
128
(5.04)
144
(5.67)
96.0
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
26.5
(1.04)
5
(0.20)
M5
1.5
(3.3)
4004E
108
(4.25)
128
(5.04)
182.5
(7.19)
96.0
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4005E
108
(4.25)
128
(5.04)
199
(7.83)
96.0
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4007E
108
(4.25)
128
(5.04)
199
(7.83)
96.0
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4009E
108
(4.25)
128
(5.04)
199
(7.83)
96.0
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4012E
140
(5.51)
128
(5.04)
193
(7.60)
128.0
(5.04)
6
(0.24)
118
(4.65)
5
(0.20)
65
(2.56)
5
(0.20)
M5
2.6
(5.7)
■ 2030 to 2082, 4018 to 4060
Figure 10.4 Exterior and Mounting Dimensions
Table 10.32 Three-Phase 200 V Class (IP20/UL Open Type, without Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
2030A
140
(5.51)
260
(10.24)
140
(5.51)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.4
(7.5)
2042A
140
(5.51)
260
(10.24)
140
(5.51)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.6
(7.9)
