11.13 o: Keypad-Related Settings
436 YASKAWA SIEPC71061753C GA500 Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-31
(11B4)
RUN
Custom Monitor 8
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the eighth line.
0
(0, 101 - 999)
760
o1-32
(11B5)
RUN
Custom Monitor 9
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the ninth line.
0
(0, 101 - 999)
760
o1-33
(11B6)
RUN
Custom Monitor 10
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the 10th line.
0
(0, 101 - 999)
760
o1-34
(11B7)
RUN
Custom Monitor 11
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the 11th line.
0
(0, 101 - 999)
760
o1-35
(11B8)
RUN
Custom Monitor 12
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the 12th line.
0
(0, 101 - 999)
760
o1-36
(11B9)
RUN
LCD Backlight
Brightness
Sets the intensity of the LCD keypad backlight.
3
(1 - 5)
760
o1-37
(11BA)
RUN
LCD Backlight ON/OFF
Selection
Sets the automatic shut off function for the LCD backlight.
0 : OFF
1 : ON
1
(0, 1)
760
o1-38
(11BB)
RUN
LCD Backlight Off-
Delay
Sets the time until the LCD backlight automatically turns off.
60 s
(10 - 300 s)
761
o1-39
(11BC)
RUN
Show Initial Setup
Screen
Sets the function to show the LCD keypad initial setup screen each time you energize
the drive. This parameter is only available with an LCD keypad.
0 : No
1 : Yes
1
(0, 1)
761
o1-40
(11BD)
RUN
Home Screen Display
Selection
Sets the monitor display mode for the Home screen. This parameter is only available
with an LCD keypad.
0 : Custom Monitor
1 : Bar Graph
2 : Analog Gauge
3 : Trend Plot
0
(0 - 3)
761
o1-41
(11C1)
RUN
1st Monitor Area
Selection
Sets the horizontal axis value used to display the monitor set in o1-24 [Custom Monitor
1] as a bar graph. This parameter is only available with an LCD keypad.
0 : +/- Area ( - o1-42 ～ o1-42 )
1 : + Area ( 0 ~ o1-42 )
0
(0 - 1)
762
o1-42
(11C2)
RUN
1st Monitor Area Setting
Sets the horizontal axis value used to display the monitor set in o1-24 [Custom Monitor
1] as a bar graph. This parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
762
o1-43
(11C3)
RUN
2nd Monitor Area
Selection
Selects the horizontal range used to display the monitor set in o1-25 [Custom Monitor
2] as a bar graph. This parameter is only available with an LCD keypad.
0 : +/- Area ( - o1-44 ～ o1-44 )
1 : + Area ( 0 ~ o1-44 )
0
(0 - 1)
762
o1-44
(11C4)
RUN
2nd Monitor Area
Setting
Sets the horizontal axis value used to display the monitor set in o1-25 [Custom Monitor
2] as a bar graph. This parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
762
o1-45
(11C5)
RUN
3rd Monitor Area
Selection
Sets the horizontal axis value used to display the monitor set in o1-26 [Custom Monitor
3] as a bar graph. This parameter is only available with an LCD keypad.
0 : +/- Area ( - o1-46 ～ o1-46 )
1 : + Area ( 0 ~ o1-46 )
0
(0 - 1)
762
o1-46
(11C6)
RUN
3rd Monitor Area Setting
Sets the horizontal axis value used to display the monitor set in o1-26 [Custom Monitor
3] as a bar graph. This parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
762
o1-47
(11C7)
RUN
Trend Plot 1 Scale
Minimum Value
Sets the horizontal axis minimum value used to display the monitor set in o1-24
[Custom Monitor 1] as a trend plot. This parameter is only available with an LCD
keypad.
-100.0%
(-300.0 - +299.9%)
762
